Product Name

Product Name : BODY WORN CAMERA

Model No.: BC102

Key Features

High quality recording: Record resolution up to 2688x1512 (1512P).

Live streaming: The camera has the ability to stream in real time via 4G or WiFi

kconnectivity. High quality video can now be seen live in the control center allowing

kreal-time situational awareness and decision making. The operator can
also

k
understand the wearer's position by built-in GPS. Alternatively,
camera wearer can

ksend an alert back to a control centre with their live video, GPS
location details.

18-Hour full shift battery life: 2 replaceable batteries and up to 18-hour working

klife ensures your camera lasts a whole shift which is critical to ensure recording

kcapability.


Record file protection: Using the AES256 encryption technology, the record file

kin the camera will be safe and be protected from unauthorized access.


Interphone function: By pressing the PTT button on the camera, the camera can

kwork like a walkie talkie and talk to other cameras anywhere in the world via 4G or

kWifi connectivity.


Foot pursuit activation: With a built-in accelerometer, the camera can detect

kwhen an officer is running and trigger recording, allowing the officer to focus on

kremaining safe during a high-stress encounter.


Facial recognition: The camera can scan and recognize the faces of potentially

keveryone they see while on patrol.


Rugged and waterproof: With rugged design and IP56 waterproof, the camera

kstands up to the most extreme environments. The camera can survive froms drops &

kimpact.It can also be used in the rain, dust and extreme temperatures.

Specification


OS

OS

Linux

Startup time

8s

Language

English / Russian / Spanish / Korean

Screen

2-inch color LCD

Recording video resolution

2688×1512/2560×1440/2304×1296/1920×1080

Recording frame rate

25fps@(2688×1512)/30fps@(2560×1440)/30fps@(2304×1296)/30fps@(1920×1080)

Record mode

Record video&audio altogether, independent dual stream for local recording and live view video.

Live view video resolution

2688x1512,2560x1440,1920x1080,1280x720

Audio

Audio input

1x MIC input, support intercom connection with USB

Audio output

Built-in high-quality speaker

External audio port

2.5mm headphone jack, support headphone, microphone and PTT

Compression

PCM

Audio record

Support record auido file only


Performance

8640x4752 / 7680x4288 / 5760x3216 / 1920x1080 optional

Snap

Support capturing pictures from live video

Photo file format

JPG

Burst shooting

5/10/20/25 pictures at a time

Lens

Lens

5 million pixels HD lens

Angle

105 degrees (HOV)

Digital zoom

8X

Geometric distortion

less than 16%

Storage

Data storage

Built in 32GB TF card(optional up to 256GB)

Night vision

Night vision

Night vision automatically/manually turned on in low light environment

Performance

Up to 7 meters with visible face detection

Light source

Flash light

To increase brightness when you are recording or taking a photo

Laser

Auxiliary locking imaging center or laser marking

Connectivity

USB

1x USB Mini port

External camera

External camera

Support external 1080P HD IR camera (optional)

Network

Protocol

TCP/IP, RTSP, RTMP, GB/28181

3G/4G

FDD-LTE/TDD-LTE/WCDMA/EVDO/GPRS

WiFi

Support (optional)

Bluetooth

Bluetooth 4.0 (optional)

GPS

Positioning

Built-in GPS. Support GPS/GLONASS (optional

Firmware

Facial recognition

Face recognition with deep learning algorithm, massive local blacklist or cloud recognition (optional)

Plate number recognition

Support (optional)

Voice control

Support (optional)

G-Sensor

Support (optional)

Voice broadcast

Support (optional)

Playback

Support local playback, search video files by time, alarm, etc.

Remote view

Support remote online playback & file download

Interphone

Support (optional)

On screen display

Date, time, device ID, user number, location information, speed information, etc.

Overwrite

Support

Playback speed

Fast forward/backward 1~128 times

Pre&Post event buffer

10s pre-recording, 60s post-recording

Password authorization

Support

Encryption

AES256 encryption

Log

Support

Software

hPlayer

Play back multiple cameras files together, including the encrypted files. At the same time it analyzes the data information in the file.

CMSV6

Support real-time preview & positioning, track playback, intercom, remote command issuance, etc.

Upgrade

Firmware upgrade

Upgrade via USB interface or remote upgrade on CMSV6

Power

Battery capacity

2*2700mAh batteries

Backup battery

Built-in 60mAh battery to ensure continuous power during replacement.

Working hour

18 hours of continuous recording @1920x1080 (two batteries)

Charging time

1A power adaptor, 4 hours charging

Working environment

Operating Temperature

-30--55

Humidity

40%80%

Other

Cradle

Charging and USB data transfer

Time

Support time synchronization with network, computer or GPS

Light indicator

Light indicators for charging, idle, video recording, photo, audio recording

IP rating

IP56

Drop

2m

Size

3.48" x 2.32" x 1.35" ( 88.4mm x 59mm x 34.3mm)

Weight

7.13oz (202g)
